CE Certification Hydraulic Four Post Car Parking Lift for 4 Cars Storage Manufacturer, Products

The CHFL2+2 is an innovative double-layer parking lift designed to provide four parking spaces within a compact footprint—two on the upper platform and two on the lower. With a maximum load capacity of 3000 kg totally, it can reliably accommodate a wide range of cars and SUVs. Its unique double-wide structure allows both upper platforms to lift and lower simultaneously, significantly boosting parking efficiency and operational convenience. Ideal for residential buildings, commercial garages, and vehicle storage centers, the CHFL2+2 offers a practical, space-saving solution that combines high performance, easy operation, and enhanced parking flexibility.

Product Description

Products Feature

4 Cars Four Post Parking Lift
◈
Double-wide design that can accommodate four vehicles, efficiently utilizing limited parking space.
◈
Customizable layout to fit specific needs, from small garages to large-scale parking lots.
◈
Dual safety locks: integrated adjustable lock ladder and automatic wire rope break activation.
◈
Flexible runway design accommodates both wide and narrow vehicles easily.
◈
Total lifting capacity of 3000 kg, suitable for sedans and SUVs.
◈
Multi-position safety locks on each column for enhanced stability.
◈
Hidden single hydraulic cylinder design for a sleek look and smooth operation.
◈
Increased pulley diameter to reduce cable fatigue and extend service life.
◈
Mechanical anti-fall locks allowing for multiple stop heights and maintenance requirements.
◈
Customizable power unit and control panel positions for user-friendly operation.
◈
Protective devices prevent wire rope loosening and breakage.
◈
Surface treated with powder coating for aesthetic appeal and corrosion resistance.
4 Cars Four Post Parking Lift Detail

Specifications

Model No. CHFL2+2
Lifting Capacity 3000 kg
Lifting Height 1965 mm
Width between Runways 3823mm
Lock Device Dynamic
Lock release Electric auto release
Drive Mode Hydraulic Driven + Cable
Power Supply / Motor Capacity 220/380v, 50 / 60Hz, 1/3Ph, 2.2Kw
Safety Device Anti-falling Device
Operation Mode Hydraulic Drive + Steel Wire Rope

Drawing & Case

Technical Drawing
Case Study 1
Case Study 2
Case Study 3

Frequently Asked Questions

Q: What is the total lifting capacity of the CHFL2+2 model?
A: The lift has a substantial total lifting capacity of 3000 kg, making it suitable for a wide range of vehicles, including sedans and SUVs.
Q: How many vehicles can this parking lift accommodate?
A: It features a double-wide design that can park four vehicles in a single setup, which is an efficient solution for limited space areas.
Q: What safety mechanisms are included in this lift?
A: The system includes dual safety locks (adjustable ladder and wire rope break activation), multi-position locks on columns, and mechanical anti-falling devices.
Q: Can the lift be customized for specific garage layouts?
A: Yes, the design is highly customizable. Both the power unit and control panel positions can be adjusted according to your specific environment and operational needs.
Q: How does the surface treatment ensure durability?
A: The surface is treated with a high-quality powder coating, which provides a professional look while protecting the structure from corrosion for long-term use.
Q: Does the lift accommodate different vehicle widths?
A: Yes, the runway is designed with flexibility in mind to ensure both wide and narrow vehicles can enter and exit without difficulty.
